所屬品牌:
所屬類別:板材打磨設備
采購可留言電話號碼,我們會與您聯(lián)系! 點擊進入1688查看更多產品
Purchase please leave a message phone and email, we will contact you!
| 產品型號 | Name | 單位 | HLDM-1800 |
| 主電機功率 | Power of main motor | kw | 11 |
| 工作平臺尺寸 | Working platform dimensions | mm | 3200 x 2000 |
| 需要氣壓 | Air pressure required | Mpa | 0.3 - 0.5 |
| 最大加工尺寸 | Max. processing dimensions | mm | 3200 x 3200 x 60 |
| 工作臺傾斜 | Working platform tilting degree | n° | 0-85 |
| 拋光頭轉速 | R.P.M. of polishing head | r/min | 550 |
| X軸進給速度 | X axis feeding speed | mm/min | 5300 |
| Y軸進給速度 | Y axis feeding speed | mm/min | 4000 |
| 耗氣量 | Air consumption | m3/min | 0.15 - 0.3 |
| 耗水量 | Water consumption | m3/h | 4 |
| 總重量 | Gross weight | kg | 7000 |
| 機臺尺寸 | Dimension (L x W x H) | mm | 6000 x 5000 x 2800 |
溫馨提示:如果想了解更多細節(jié),規(guī)格、標準、價格和解決方案,請聯(lián)系我們。
